DISC - Fender American Deluxe Dimension IV Bass - Violin Burst

SKU 08FEN085
by Fender
Sold out
Original price $ 1,099.00 - Original price $ 1,099.00
Original price
$ 1,099.00
$ 1,099.00 - $ 1,099.00
Current price $ 1,099.00

Enter a new dimension of Fender bass. Dimension basses now take their place among Fender’s greatest bass designs as the modern pinnacle of pro-level bass style, power, performance and personality.

The company that invented electric bass now brings you an elegantly original body style with all-new pickups, electronics and other fine features that let you sculpt and personalize your tone as no Fender bass ever has before. It is a level of bass artistry unparalleled in Fender history, and it is the future of your Fender bass experience. In every way, it’s an entirely new Dimension in Fender bass.

The American Deluxe Dimension Bass IV is a phenomenal instrument, with an ash body in the completely new Dimension shape and featuring a comfortable asymmetrical neck heel. Its maple neck is crafted with a great-feeling asymmetrical “C”-shaped profile, Posiflex™ graphite neck support rods, a convenient heel-mount truss rod adjustment wheel, smooth hand-rubbed oil finish and five-bolt neck plate. The compound-radius (9.5”-14”) maple or rosewood fingerboard has 21 medium jumbo frets and a bone nut, while the headstock has a gloss finish and Stealth “A” string retainer.

The instrument’s sonic sophistication is simply unmatched. Its single Dimension Bass humbucking pickup is both powerful and nuanced, and its 18-volt onboard preamp, three-band active EQ (center-detented treble, mid and bass boost/cut) and master volume deliver remarkable tonal versatility with any degree of muscle and finesse. Other premium features include a three-ply black pickguard, knurled chrome control knobs, Fender HiMass™ bridge, vintage-style tuners with tapered shafts, locking strap buttons, side-mounted oval output jack and rear-mounted battery compartment. Available in elegant Natural, Black, Cayenne and Violin Burst gloss finishes. Hard-shell case, leather strap and 10’ cable included.

Product Specs

Model Name
American Deluxe Dimension™ Bass IV, Rosewood Fingerboard, Violin Burst
Model #
0195400733
Series
American Deluxe
Country Of Origin
US
Color
Violin Burst
Body
Ash
Body Finish
Gloss Polyester
Body Shape
Dimension Bass®
Neck Material
Maple
Neck Finish
Hand-Rubbed Oil Finish with Gloss Urethane Headstock Face
Neck Shape
Asymmetrical "C"
Scale Length
34" (864 mm)
Fingerboard
Rosewood
Fingerboard Radius
9.5" to 14" Compound Radius (241 mm-355.6 mm)
Number of Frets
21
Frets Size
Medium Jumbo
String Nut
Bone
Nut Width
1.625" (41.3 mm)
Position Inlays
Pearloid Dots
Truss Rods
Posiflex™; Graphite Neck Support Rods
Bridge Pickup
Dimension™ Humbucking
Controls
Master Volume, Three-Band Active EQ with Treble Boost/Cut, Bass Boost/Cut and Mid Boost/Cut
Pickup Switching
Pan Pot
Pickup Configuration
H
Bridge
Fender HiMass™ with Chrome-Plated Brass Saddles
Hardware Finish
Chrome
Tuning Machines
Fender® "F" Light-Weight Vintage-Paddle Keys with Tapered Shafts
Pickguard
3-Ply Black
Control Knobs
Knurled Flat-Top
Strings
Fender® USA Bass 7250M, NPS (.045-.105 Gauges)
Unique Features
Asymmetrical Neck Heel, Stealth "A" String Retainer, Heel-Mounted Spoke Wheel Truss Rod Adjustment, Vintage-Style Knurled Control Knobs, 5-Bolt Neckplate
